Estar EVD50G12DA2 12V Contactor, Aux: Normally Open, Continuous duty

The Estar EVD50G12DA2 is a 12V single pole, single throw (SPST-NO) DC contactor from Estar's EVD series, rated for 50A continuous current at up to 1000V DC. It is fitted with an auxiliary switch (normally open) for remote monitoring of the main contact position.

Epoxy sealed and nitrogen-filled for a hermetically sealed contact chamber, the EVD50G12DA2 is designed for demanding DC switching duties in EV, battery storage, and industrial power systems. The single pole, normally open main contacts are non-polarised, so the contactor can be wired without regard to current direction, and are suitable for interrupted and continuous switching of resistive, inductive, and capacitive loads. The 12V coil is continuously rated, giving reliable, sustained operation without the need for a PWM economiser circuit.

Features & Benefits:

• Single pole, single throw, normally open main contacts rated at 50A continuous (max breaking current 1000A at 320V DC, single operation)
• 12V DC continuously-rated coil, drawing approximately 5.5W coil holding power
• Auxiliary switch fitted — normally open contact for main-contact status monitoring
• Contact resistance of ≤1mΩ at 50A, initial insulation resistance of 1000MΩ
• Epoxy sealed, nitrogen-filled contact chamber for long service life in harsh environments
• Mechanical life rated at 3×10⁵ cycles
• Operating temperature range of -40°C to +85°C, altitude to 4000m
• Tested to EN 60947-4-1, CE marked with EU Declaration of Conformity available

Applications include:

• EV and HV battery isolation and main contactor duty
• Battery pack switching for e-mobility and energy storage systems
• Marine and aviation power systems
• Robotics and autonomous vehicle platforms
• Agricultural and low-volume OEM machinery
