Hook Up Wire 1.0mm² (32/0.2mm) BS4808 Part 3 / Def Stan 61-12 Part 6 500m (1640ft) - White

BS4808 Part 3 / Def Stan 61-12 Part 6 stranded equipment wire, supplied as a 500m reel in White. 1.0mm² (32/0.2mm) tinned annealed copper conductor construction rated to 1500V (AC).

Also known as "hook-up" or "equipment" wire, this general-purpose single-core cable is used throughout marine, aviation, industrial and automotive wiring looms wherever a flexible, low-current control or signal conductor is needed. The tinned copper strands resist corrosion in damp or marine environments, while the Type 3 hard-grade PVC insulation gives good mechanical and chemical resistance across a wide operating temperature range.

Features & Benefits:

• 1.0mm² (32/0.2mm) flexible tinned annealed copper conductor for good flex-life and corrosion resistance
• Rated 1500V (AC) and 6A continuous at 70°C
• Conductor resistance 19.1 Ω/km max at 20°C
• Wide operating temperature range of -20°C to +85°C (only slight flexing permitted at -20°C)
• Manufactured to Def Stan 61-12 Part 6 and BS4808 Part 3
• RoHS compliant
• Supplied on a 500m reel

Applications include:

• General equipment and control panel wiring
• Marine and aviation wiring looms
• Industrial machine and robotics wiring
• Low-voltage signal and instrumentation wiring
• Automotive and off-highway auxiliary wiring
